3.2tons Durable Commercial Knuckle Boom Truck Mounted Crane

Truck loader crane Isuzu

Details

3.2tons Durable Commercial Knuckle Boom Truck Mounted Crane

3.2tons Durable Commercial Knuckle Boom Truck Mounted Crane



Durable Commercial Knuckle Boom Truck Mounted Crane, 3200kg 6.72 T.M Lifting



  1. Name: Knuckle boom crane, Lorry mounted crane, Cargo crane truck, Truck loader crane, Hydraulic truck crane
  2. Max Lifting Capacity: 3200 kg
  3. Max Lifting Moment: 6.72 t.m
  4. Max Oil Flow of Hydraulic System: 25 L/min
  5. Max. Lifting height:8.5meters
  6. Brand: XCMG
  7. Crane Weight: 1100 kg
  8. Oil Tank Capacity:60 L
  9. Feature: Safety transportion, driven by hydraulic, move fast. The raise and down are driven by wire rope.
  10. Application: used in Commercial, transportation, oil, balance check, telecommunications, electricity, municipal services and other occasions.





Description:



Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.


Knuckle boom crane SQ3.2ZK1 is used for lifting 3.2tons, moment is 6.72T.M.





Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.

Knuckle boom cranes can be configured to do just about any job imaginable, from delivering products to cleaning up debris after the job is done.



Specifications:



Model

SQ3.2ZK1

Unit

Max Lifting Moment

6.72

t.m

Max Lifting Capacity

3200

kg

Recommend Power Needed At Recommend Oil Flow

14

kw

Max Oil Flow of Hydraulic System

25

L/min

Rated Pressure Of Hydraulic System

22

MPa

Oil Tank Capacity

60

L

Rotation Angle

370

º

Crane Weight

1100

kg

Installation Space

850

mm

Choice of Chassis

ISUZU

SQ3.2ZK1 Lifting capability diagram

Working radius (m)

2.1

4.15

5.8

Lifting capacity (kg)

3200

1400

1000




 Optional parts:



1, Moment limited device

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

2, Remote control equipment

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

3, Anti-overwind magnet valve

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

4, High seat on column

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

5, Work light

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

6, Assistant stabilizer leg

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm
