Best Isuzu 25 Ton Knuckle Boom Truck Mounted Crane Driven By Hydraulic

XCMG Truck Mounted Crane ,Truck Crane,XCMG Crane

Details

Best  Isuzu 25 Ton Knuckle Boom Truck Mounted Crane Driven By Hydraulic

Best Isuzu 25 Ton Knuckle Boom Truck Mounted Crane Driven By Hydraulic

Durable XCMG 25 Ton Knuckle Boom Truck Mounted Crane Driven By Hydraulic



  1. Name: Folding boom crane, Folding boom truck crane, Knuckled boom crane, Knuckle boom truck mounted crane
  2. Max Lifting Capacity: 25 ton
  3. Max Lifting Moment: 62.5 t.m
  4. Max Oil Flow of Hydraulic System: 80 L/min
  5. Max. Lifting height:19meters
  6. Brand: XCMG
  7. Crane Weight: 7945 kg
  8. Oil Tank Capacity: 300 L
  9. Feature: Safety transportion, driven by hydraulic, move fast. The raise and down are driven by wire rope.
  10. Application: used in Commercial, transportation, oil, balance check, telecommunications, electricity, municipal services and other occasions.





Description:



Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.


Knuckle boom crane SQ25ZK6Q is lifting capacity is 25tons, moment is 62.5T.M.





Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.





Specifications:



Model

SQ25ZK6Q

Unit

Max Lifting Moment

62.5

t.m

Max Lifting Capacity

25000

kg

Recommend Power Needed At Recommend Oil Flow

50

kw

Max Oil Flow of Hydraulic System

80

L/min

Rated Pressure Of Hydraulic System

31.5

MPa

Oil Tank Capacity

300

L

Rotation Angle

(360°) All Rotation

.

Crane Weight

7945

kg

Installation Space

3000

mm

Choice of Chassis

ISUZU



 SQ25ZK6Q Lifting capability diagram

Working radius(m)

2.5

4.22

5.93

7.74

9.59

11.48

13.43

15.45

Lifting capacity(kg)

25000

14000

9000

6500

5000

4000

3000

2500



Optional parts:



1, Moment limited device

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

2, Remote control equipment

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

3, Anti-overwind magnet valve

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

4, High seat on column

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

5, Work light

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

6, Assistant stabilizer leg

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm
