Durable isuzu 3200kg Folding Boom Truck Mounted Crane

Isuzu chassis Knuckle boom truck mounted crane

Details

Durable isuzu 3200kg Folding Boom Truck Mounted Crane

Durable isuzu 3200kg Folding Boom Truck Mounted Crane

Durable Folding Boom Truck Mounted Crane, 6.72 T.M Hydraulic Truck Mounted Crane



  1. Name: Folding boom crane, Folding boom truck crane, Knuckled boom crane, Knuckle boom truck mounted crane
  2. Max Lifting Capacity: 3200 kg
  3. Max Lifting Moment: 6.72 t.m
  4. Max Oil Flow of Hydraulic System: 25 L/min
  5. Max. Lifting height:10.5meters
  6. Brand: XCMG
  7. Crane Weight: 1200 kg
  8. Oil Tank Capacity:60 L
  9. Feature: Safety transportion, driven by hydraulic, move fast. The raise and down are driven by wire rope.
  10. Application: used in Commercial, transportation, oil, balance check, telecommunications, electricity, municipal services and other occasions.





Description:



Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.



Knuckle boom crane SQ3.2ZK2 is used for lifting 3.2tons, moment is 6.72T.M.





Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.



Specifications:



Model

SQ3.2ZK2

Unit

Max Lifting Moment

6.72

t.m

Max Lifting Capacity

3200

kg

Recommend Power Needed At Recommend Oil Flow

14

kw

Max Oil Flow of Hydraulic System

25

L/min

Rated Pressure Of Hydraulic System

22

MPa

Oil Tank Capacity

60

L

Rotation Angle

370

º

Crane Weight

1150

kg

Installation Space

850

mm

Choice of Chassis

ISUZU



SQ3.2ZK2 Lifting capability diagram

Working radius (m)

2.1

4.15

5.8

7.3

Lifting capacity (kg)

3200

1300

950

650



Optional parts:



1, Moment limited device

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

2, Remote control equipment

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

3, Anti-overwind magnet valve

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

4, High seat on column

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

5, Work light

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

6, Assistant stabilizer leg

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm
