SQ14ZK4Q 14 Ton Transportation Isuzu Hydraulic Knuckle Truck Mounted Crane

Mini Isuzu Truck Mounted Cranes for Sale

Details

14 Ton Transportation Isuzu Hydraulic Knuckle Truck Mounted Crane

14 Ton Transportation Isuzu Hydraulic Knuckle Truck Mounted Crane



14 Ton Transportation XCMG Hydraulic Knuckle Boom Truck Mounted Crane



  1. Name: Knuckle boom crane, Lorry mounted crane, Cargo crane truck, Truck loader crane, Hydraulic truck crane
  2. Max Lifting Capacity: 14 ton
  3. Max Lifting Moment: 35 t.m
  4. Max Oil Flow of Hydraulic System: 63 L/min
  5. Max. Lifting height: 14meters
  6. Brand: XCMG
  7. Crane Weight: 4800 kg
  8. Oil Tank Capacity: 220 L
  9. Feature: Safety transportion, driven by hydraulic, move fast, The raise and down are driven by wire rope.
  10. Application: used in Commercial, transportation, oil, balance check, telecommunications, electricity, municipal services and other occasions.





Description:



Knuckle boom crane, help you loading goods on your truck. The crane will fold to compact size after working and will not affect the space of the carriage. The arms are driven by hydraulic, move fast, more effective. The arms can easy to reach narrow spaces like inside the workshop. More accessories like fork, grab bucket, can be attached for different goods loading.



Knuckle boom crane SQ14ZK4Q is lifting capacity is 14tons, moment is 35 T.M.





Applications:



It can be applied on most common Commercial Truck-mounted Cranes. Range covers light to medium crane. With small mounting size and weight to save your payload, minimizing loading and unloading time, is the best choice of truck mounted crane facilities.

Knuckle boom cranes can be configured to do just about any job imaginable, from delivering products to cleaning up debris after the job is done.



Specifications:



Model

SQ14ZK4Q

Unit

Max Lifting Moment

35

t.m

Max Lifting Capacity

14000

kg

Recommend Power Needed At Recommend Oil Flow

32

kw

Max Oil Flow of Hydraulic System

63

L/min

Rated Pressure Of Hydraulic System

26

MPa

Oil Tank Capacity

220

L

Rotation Angle

(360°) All Rotation

.

Crane Weight

4800

kg

Installation Space

1300

mm

Choice of Chassis

ISUZU



SQ14ZK4Q Lifting capability diagram

Working radius(m)

2.5

4.046

5.826

 7.646

9.516

11.4

Lifting capacity(kg)

140000

 8400

5478

4080

3148

245



Optional parts:



1, Moment limited device

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

2, Remote control equipment

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

3, Anti-overwind magnet valve

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

4, High seat on column

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

5, Work light

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

6, Assistant stabilizer leg

 Isuzu Truck Mounted Crane, ISUZU Telescopic boom crane, Isuzu Crago truck with crane, Isuzu lorry body crane

Stabilizer leg

Spread

Fixed

2179mm

Single extension

2256-3556mm

Double extension

2212-4752mm
