12016 Brand New NPR NQR Fire Engine ISUZU with 3,000L capacity
Main specifications:
ELF/700P Mid-duty chassis for Fire-fighting application |
||
Model |
PT5110GXF |
|
Driving Type |
4x2 (Left hand drive) |
|
Wheelbase |
3815 mm |
|
Overall Dimension |
7410×2290×3190 mm |
|
Tank capacity |
3000L water |
|
Fire Pump |
Rated low pressure:1.0MPa, Flow rate:30L/S. Rear-mounted,Water delivery time:≤35s |
|
Fire Cannon |
Rated pressure≤1.0MPa,Rated Flow rate:20L/s, Throw range≥50m, Rotation angle:360°, |
|
Cab |
Double cab with Four doors, 5 seats with safe belts. |
|
Engine |
Model: |
4HK1-TCG40 |
Type: |
Diesel, turbo charged inter-cooled, 4 cylinder |
|
Max. Power: |
139 KW (190HP) |
|
Gearbox |
MLD 6-shift, mechanical type, 6 forward and 1 reverse with |
|
Tire |
8.25-16 |
|
Color |
Red (Any color & logos up to wish) |
|
Max Speed |
100 km/h |
Detail pictures of NPR ELF Water Fire Engine Truck to Mongolia:
|
|
Front left view |
Front right view |
|
|
Left side view | Right side view |
|
|
Rear left view |
Rear right view |
|
|
Front view | Rear view |
Customer Special requirement for add water sprinkler system
Pump room
Pump room
Seat
Suction hose
Accessories List:
(With below equipment, you can put into fire-fighting immediately)
