Isuzu FVR 8-Ton Truck-Mounted Crane: The "All-Rounder" for Heavy Lifting and Cargo Hauling If you need a workhorse that can both "reach new heights" and "haul heavy loads," the Isuzu FVR 8-ton truck-mounted crane is a beast you can’t ignore. Built on the rugged Isuzu FVR GIGA 5X chassis, it’s powered by the robust 6HK1-TCG61 240HP engine and paired with a smooth-shifting 8-speed manual transmission from Fast Gear—delivering steady power, effortless climbing, and unstoppable towing capability. Chassis & Powertrain: Stable as a Mountain, Powerful as a Tiger Mighty Engine: The 6HK1-TCG61 engine, a 240HP workhorse, cranks out 850N·m of torque at low RPMs. It’s fuel-efficient, built to last, and the definition of an "endurance runner" in the engineering vehicle world.   Seamless Shifting: The Fast Gear 8-speed transmission offers clear gear ratios and buttery-smooth shifts. Whether navigating city streets or rugged construction sites, it handles both with ease.   Optimal Wheelbase: The FVR GIGA 5X chassis inherits Isuzu’s legendary "steel backbone" durability. With a 4,500mm wheelbase, it balances tight-turn maneuverability and highway stability, making it a jack-of-all-trades. ISUZU FVR 8T boom crane truck General Technical Parameters Overall Dimension 9700x2480x3650mm Gross Vehicle Weight 18000(Kg) Curb Weight 9800(Kg) Chassis Specification Chassis Brand Isuzu Drive model 4x2,LHD Cabin Isuzu FVR 5X chassis,2 seats with a sleeper, Left Hand Driving, with air conditional Engine Model 4-stroke direct injection , 6-cylinder in-line with water cooling, inter-cooling, EGR Type Isuzu 6HK1-TCG61 Power 176KW/240HP Emission standard EURO 6 Displacement 7780ml Max torque 850N.m Fuel type Diesel Gearbox FAST 8 speed, 8forward gears, 1 reverse gears Brake System Air brake Wheel Base 4500mm Front/Rear Axle Loading 6500/11500Kg Tire 295/80R22.5, 6+1 pcs Max Driving Speed 95km/h Superstructure Specification Cargo Body Dimension 5500*2350*550mm Material Q235 carbon steel Cargo Thickness Side 3mm, Bottom 4mm Working System Boom Type Straight 5-Arm telescopic boom Crane Crane Brand SQ-8 Max Lifting Moment 20T·M Max extension length 16.5m Max Lifting Capacity 8000kg Max lifting height 18.5m Rotation angle 360° Installation space 1200mm Maximum working pressure 27Mpa Recommended flow rate 55L/min Crane weight 3250kg Oil tank capacity 160L Leg Leg type H type Leg Span 4500mm     Upper Structure: SQ-8 Crane – 5-Section Arm Masters Aerial Operations The soul of this machine lies in its SQ-8 synchronous telescopic boom crane. With a 5-section design, it lifts up to 8 tons and reaches 18.5 meters (equivalent to a 6-story building). The 360° rotation capability turns it into a master of lifting, transporting, and aerial work.   Smooth Telescoping: The 5-section boom extends and retracts synchronously, ensuring fluid, jitter-free operations and peak efficiency.  ...

Isuzu GIGA 8×4 Truck-Mounted Crane: Reshaping Efficiency Benchmarks in Engineering Operations In the realm of engineering transportation and heavy-duty lifting, the Isuzu GIGA 8×4 truck-mounted crane stands out as a "game-changer" for municipal projects, bridge construction, and mining operations. Its innovation across chassis design, powertrain systems, and lifting mechanisms—combined with XCMG's high-quality crane technology—sets a new industry standard. Below, we dissect its core technical advantages to explain why it is the ideal choice for efficient operations. I. Powertrain & Transmission: Low-RPM High-Torque Precision   ● Isuzu 6WG1-TCG62 Engine: The "Heart" of Engineering Operations Engine Specifications: The 6WG1-TCG62 engine boasts a 15.7L displacement, delivering 520 horsepower and a peak torque of 2,250 N·m at 900–1,300 RPM. Compliant with Euro 6 emission standards, it balances environmental protection with robust power output.   Advanced Technologies: High-pressure common-rail injection and turbocharged intercooling systems enable instant torque delivery at low RPMs, ideal for challenging conditions such as hillside lifting and heavy-load startups. Paired with a 12-speed FAST transmission, it ensures seamless gear shifts and precise power distribution for both highway economy and off-road terrain. II. Ultra-Strong Load-Bearing & Stability Design   ● Chassis & Axle Configuration Optimization 8×4 Drive Layout: With a total mass capacity of 44 tons and an axle spacing of 2,100+4,325+1,370mm, it balances steering agility with even load distribution.   Cargo Box Durability: Measuring 7,000×2,350×550mm with 4mm side walls and 5mm floor plates, it ensures large-volume loading and structural rigidity under heavy loads.   ● Tires & Suspension Systems 12R22.5 Tires: Provide exceptional ground contact area and grip, minimizing slip risks.   Multi-Axle Balanced Suspension: Distributes heavy loads evenly, safeguarding chassis stability. III. Lifting System: XCMG GSQS500-5 Straight-Arm Crane Breakthroughs   The next-generation G-series straight-arm crane features strengthened synchronized telescopic mechanisms, superior load-bearing telescoping capabilities, and a proprietary confluence proportional control system for precise, stable, and user-friendly operations. Key features include automatic hook retraction for safety, optional accessories (secondary hooks, work platforms, remote controls, torque limiters), and flexible configurations.   ● Five-Section Synchronized Telescopic Boom: 23.7m Radius & 520kN·m Torque Lifting Efficiency: The 23.7m boom extends to cover a 20m radius when fully deployed (8,396mm leg span). With a 520kN·m torque rating and a 7,600kg crane weight, it ensures precision and stability. For example, in municipal projects, its 23.7m radius reduces vehicle repositioning, accelerating timelines.  ...

A new milestone in China-Arab cooperation: POWERSTAR TRUCKS helps Algeria mass-customize 2026 Isuzu GIGA chassis trucks ‌ Driven by the Belt and Road Initiative, China and Algeria's economic and trade cooperation continues to deepen. Recently, a large Algerian transportation group reached a strategic cooperation with POWERSTAR TRUCKS, a well-known commercial vehicle company in my country, to purchase in batches the 2026 Algeria Isuzu GIGA cab chassis truck developed specifically for the North African market. This cooperation not only demonstrates the strength of Made in China in the field of special vehicles, but also injects new momentum into Algeria's infrastructure construction.       Customized chassis matches diverse needs ‌ The chassis vehicle delivered this time adopts the Isuzu GIGA special vehicle dedicated platform, equipped with a 6WG1 series 460 horsepower large-displacement engine, and equipped with a ZF 16-speed intelligent gearbox. The power combination can perfectly adapt to the complex terrain conditions in Algeria. From the oil and gas fields on the edge of the Sahara Desert to the mining areas in the Atlas Mountains, the ground clearance and cooling system of this model have been optimized in a targeted manner. Customers can flexibly modify it into a dump truck, water truck or freight truck according to actual needs. This "one chassis for multiple uses" design concept is in line with Algeria's diverse transportation scenarios from the coastal city of Algiers to the inland province of Ouargla.   Strategic considerations behind in-depth cooperation ‌ As the largest country in Africa, Algeria has continued to promote the "Vision 2030" development plan in recent years, and plans to build 1,200 kilometers of new highways in 2025 alone. POWERSTAR TRUCKS has successfully won the favor of customers with its 15 years of industry experience in focusing on Isuzu chassis modification. The group's technical director said: "Chinese suppliers can not only provide powertrains that meet EU emission standards, but also customize cooling systems and air filtration devices for our high temperature and dusty environment. This localized adaptation capability is the key to choosing cooperation."   Market prospects and technological innovation ‌ The current Algerian commercial vehicle market is showing three major trends: Energy transformation drives renewal ‌: As the national oil company Sonatrach increases unconventional oil and gas development, traditional transport fleets are gradually being replaced by new vehicles with high efficiency and low consumption. Urbanization has given rise to special needs: The annual growth rate of demand for municipal special vehicles in large cities such as Oran and Constantine has reached 15%, especially smart sprinkler trucks and garbage sorting transport vehicles. China's technology recognition has increased: China-made chassis modification technology has been suc...

Isuzu water tank foam fire truck is a special fire truck modified based on Isuzu QL1180JQFRY type II automobile chassis. Isuzu 4HK1 model 205HP tanker fire apparatus is specially designed for fire fighting and rescue tasks, which is export to Dubai Jebel Ali seaport, and can be widely used in Dubai, Saudi Arabia, Yemen, Oman, Jordan, etc. Isuzu pumper fire truck combines water tank and foam tanker, matched with fire extinguishing CAFS system and has rapid response, efficient fire fighting and multi-functional operation capabilities. Isuzu fire tender is equipped with a dual-media storage system of water tank and foam liquid tank, and integrates fire pump, water cannon, pipeline system and rescue equipment. It is suitable for fighting various types of fires. Below video showing details of this type Isuzu fire truck.     Dubai clients customized ISUZU GIGA 4X FTR 6ton firefighting truck equipped the double-row cabinet, with a crew of 2 + 4 SCBA seats for people, and the fire engine is comfortable and light. The tanker upper body kit are equipped with water and foam tanks, the fire tanker vehicle liquid capacity is 5000kg and the foam is 1000kg. The equipment box is made of high-quality aluminum alloy roller shutter door. Chassis equipped with diesel engine model is 4HK1-TCG60, the maximum power of 151kW / 205HP, through the cardan coupling to drive the Shanghai Xiongzhen CB10/40 atmospheric fire pump installed in the rear pump room of the fire apparatus, can stably output 40L/s flow at 1.0MPa; The roof is installed with the PL8/32 fire cannon produced by Chengdu West Fire Equipment Co., Ltd., with a flow rate of 32L/s, a corresponding pressure of 0.8MPa, a maximum pressure of 1.3MPa, and a range of 60m water and 50m foam, which can be rotated 360°. At the same time, the car has the characteristics of high specific power, strong comprehensive performance, and simple control. Below showing detailed operation manual for ISUZU fire tender, which introduced of all functions of the Isuzu fire engine also the steps by steps to operate the truck correctly to avoid any misoperation.     The chassis system of fire trucks has extremely high requirements for stability, power output and continuous operation capability. Isuzu has been accumulated for a long time, with high-power engines, efficient transmission systems and high-strength frame designs, which can meet the rapid response needs of complex fire scenes. Dubai clients mostly perfer to buy reliable quality fire engine for fire extinguishing and people rescue, the ISUZU brand fire fighting trucks can always meet the requirement. As the world most reliable Isuzu fire truck manufacturer, we POWERSTAR can not only provide reliable quality Isuzu fire department trucks, but also produced detailed English version documents for operation guidance and maintenance service, including Fire Truck Operation Manual, Isuzu Truck User Manual, Isuzu Spare Parts Manual, etc. Feel free to call us at ...

POWERSTAR 2025 2026 year newly designed Combined Sewer Jetting Truck is produced and export to Moldova, Moldova customer provide detailed requirement to POWERSTAR Engineer Dept and get official recommend for the sewer jetting. Truck is based on type II ISUZU new NPR 4x2 Left Hand Drive chassis, capacity for the customized Isuzu sewer jetter truck can be up to 2,500Liters and clean water tank can be up to 1,000Liters, which also installed with best performed Chinese brand WEILONG 68-7000 model vacuum pump, also Germany brand PINFL high pressure jetting pump. The Isuzu Sewer Jetters main consist of below system: Sandwich PTO, Driving system, Belt, Vacuum pump system, High pressure jetting pump, Durable vacuum tank and water tank system, High pressure working system, Pipeline system, Vacuum gauge, View window, Washing system, etc.   Isuzu NPR 2500L+1000L combined sewer suction jetting truck is designed to fully rely on the advantages of the original of ISUZU brand chassis, the maintenance for whole truck can be easily. Tank material is international standard strength carbon steel, round shape with separated tanker, front is 1000L water tank and rear is 2500L sewage tank, which treated with anticorrosion painting both inside and outside. is ideal and special-purpose machinery used for dredging city sewer, specially applied to pumping, cleaning and transporting the sewage sludge, also can be used for suction droppings and some other works. The ISUZU vacuum truck is widely used for all kinds of suction work in city, high-way service station, airport, community, factory, etc. Therefore, the vehicle is an ideal Combined Sewer Jetting Truck mainly for Dredge sewer and liquid sewage suction. Below detailed introduce the operation steps for the Isuzu truck.     ISUZU Combined Sewer Jetting Truck is consisting of two system, vacuum sewage suction system and high-pressure clean water jetting system. The Vacuum System makes use of the PTO to get the power from truck engine and transmission, and the power drive the vacuum system working through shaft and belt. Operation the Four-Way valves to control the truck suction liquid sewage, after suction working, using Manual Hydraulic Valves to control rear door Open/Close, and sewage tanker Rise/Fall. After working, cleaning the sewage tank, and ready for next time operation. The High-Pressure Clean Water Jetting System makes use of the Sandwich PTO to get the power from truck engine and transmission, using Manual Hydraulic Valves to control the rear hose reel working, adjust the throttle knob to make jetting speed faster and stronger. Above operation manual can be kept properly and always help operater in Moldove fully understand the function, then can teach user operate the Isuzu combined sewer truck step by step to realise all functions.

Analysis of the difference between the combined jetter truck and the sewage suction truck --  Taking the Isuzu KV100 4cbm combined jetting truck and the Isuzu 100P cbm sewage suction truck as examples   With the acceleration of urbanization, the importance of urban environmental sanitation and municipal maintenance has become increasingly prominent. In the field of municipal sanitation and pipeline maintenance, the joint dredging truck and the sewage suction truck are two core equipment, each playing an indispensable role. This article aims to compare and analyze the technical parameters, functional characteristics and application scenarios of the Isuuz KV100 4cbm combined vacuum jetting truck and the Isuzu 100P 4cbm sewage suction truck, and deeply explore the difference between the two to provide a reference for users.   As important tools for urban environmental sanitation and municipal maintenance, the joint dredging truck and the sewage suction truck are widely used in the cleaning and dredging of urban sewers, septic tanks, industrial pipelines and other areas. Although the two may be similar in appearance, there are significant differences in functional positioning, technical configuration and application scenarios. This article will take the Isuzu KV100 4cbm combined dredging truck and the Isuzu 100P 4cbm sewage suction truck as examples, and conduct a comparative analysis from multiple dimensions such as chassis, upper body configuration, and functional characteristics. ★ Chassis and power system comparison 1. Isuzu KV100 4-cubic-meter joint dredging vehicle ● Chassis: Modified based on the Isuzu KV100 light truck chassis, with a wheelbase of 3360mm, ensuring the flexibility and stability of the vehicle under complex road conditions.   ● Power system: Equipped with Isuzu 4KH1CN6LB engine, maximum power 120HP, matched with Isuzu MSB 5-speed gearbox, sufficient power, smooth gear shifting, meeting the needs of efficient operation.   2. Isuzu 100P 4cbm sewage suction truck ● Chassis: Modified based on the Isuzu ELF 100P light truck chassis, with a wheelbase of 3360mm, inheriting the reliability and durability of the Isuzu chassis.   ● Power system: Equipped with Isuzu 4KH1CN6LB 120HP 88Kw diesel engine, matched with Isuzu MSB 5-speed gearbox, smooth gear shifting, meeting the needs of efficient operation. ★ Differences in upper configuration and functional design 1. Isuzu 4,000 liters combined jetting suction truck ● Tank design: The tank is divided into two parts, a 3-cubic-meter sewage tank and a 1-cubic-meter clean water tank, to collect sewage and store clean water, meeting the needs of joint dredging operations.   ● Power take-off and control system: The joint dredging vehicle needs to support both high-pressure cleaning and vacuum suction, so the power distribution is more complicated. Equipped with two power take-offs, which control the sewage tank system and the clean water tank system respect...

Isuzu GIGA 8x4 refrigerated truck is a special vehicle designed for transporting perishable goods. It is equipped with a refrigeration system that can maintain a constant low temperature environment during transportation. Its features include efficient refrigeration, precise temperature control, and good compartment sealing to ensure that the goods remain fresh during long-distance transportation. Isuzu refrigerated truck can extend the shelf life of perishable goods such as food and medicine, reduce losses, and meet the high standards of cold chain logistics. Isuzu refrigerated truck (also called refrigerator wagon,freezer vehicle, freezer wagon,termperature controlled truck,refrigerator car, preservation vehicle) is used to carry perishable stuff at specific temperatures.The cooling device could be of famous brand such as Carrier,Thermoking etc.   Isuzu GIGA 8X4 refrigerated truck is modified on the basis of Isuzu GIGA VC66 cab chassis, equipped with 1850+4575+1370mm wheelbase, 6UZ1-TCG61 380HP engine, Fast 12-speed gearbox, the vehicle adopts carrier SUPRA 1250 refrigeration unit, the internal dimensions of the vehicle body are 10500x2400x2800mm, FRP+ PU Foam + FRP 105mm material, Full Size Double Opening Rear Door.      Isuzu 8x4 refrigerated reefer box truck Chassis Chassis Isuzu GIGA 8X4 Cab Isuzu GIGA VC66 cab, two seats and one bed,with A/C,USB,direction assistance Dimension 12385x2560x4336 mm Driving type 8x4 Steering LHD Wheel base 1850+4575+1370mm GVW 44000kg Curb Weight 10350kg Transmission FAST 12-shift gearbox, manual, 12-Forwards & 2-Reverses Fuel tank 400L aluminum alloy Axle Load Front Axle: 18000kg Rear Axle: 13000kg x 2 Tire 295/80R22.5 12+1pcs, including 1 spare Engine Model Isuzu 6UZ1-TCG61 Horsepower 380HP/278Kw Speed 1800rpm Displacement 9.839L Type four strokes,6 cylinders in line with water cooling, directly injection Emission standard Diesel, Euro 6 Cargo Box Dimension 10500x2400x2800 mm Material FRP+ PU Foam + FRP 105mm Structure All Closed Sandwich Door Full Size Double Opening Rear Door Flooring Antiskid and abrasion resistant Marker Light 2 sets white on front,2 sets red on rear Celling Light 2 sets of 12/24V LED Control Panel English Refrigerator unit Brand Carrier Model Carrier SUPRA 1250 Temperature -20 deg-(0+2) deg   1.Purpose of Isuzu GIGA freezer truck  Isuzu GIGA freezer truck is mainly used to transport goods that need to be stored at low temperatures, covering multiple fields: ● Food industry: used to transport fresh food (such as meat, seafood, dairy products), frozen food (such as ice cream, quick-frozen food) and fruits and vegetables, etc., to ensure that the food remains fresh during transportation and avoids spoilage.    ● Pharmaceutical industry: used to transport temperature-sensitive drugs such as vaccines, blood products, and biological agents, to ensure that the drugs meet strict temperature control requirements during transport...

ISUZU ELF KV100 folding aerial platform truck is a special vehicle designed for aerial work. Its core feature is the folding boom structure. The boom can be folded and retracted in multiple sections, which is highly flexible and can adapt to complex working environments.  Its advantages include: wide operating range, precise positioning across obstacles; flexible operation, the boom can rotate 360 ​​degrees to achieve multi-angle operation; high stability, equipped with hydraulic outriggers and intelligent balancing system to ensure safe operation; strong adaptability, suitable for a variety of scenarios such as building maintenance, municipal engineering, and power maintenance. Isuzu KV100 14M folding boom aerial work vehicle is an efficient, flexible and safe professional equipment, widely used in construction, municipal administration, electricity, communications and other fields. It is equipped with Isuzu 4KH1CN6HB engine with a maximum power of 132hp and Isuzu MLD 6-speed gearbox, which is powerful and stable in operation.  Folding arm structure: The Isuzu NPR truck mounted folding arm aerial platform is made of high-strength steel plate and has a 360-degree full rotation function, which can achieve flexible operation. The arm is equipped with an auxiliary hook for convenient lifting operations. Working platform: The articulating working platform has a built-in combined leveling mechanism to ensure that the working bucket is always level. The rear-mounted design of the working bucket facilitates personnel entry and exit, while lowering the center of gravity of the vehicle and improving driving performance. Operating mechanism: The aerial platform operating mechanisms can be optionally equipped with an electronic control operating system, which is simple and convenient to operate. At the same time, the Isuzu truck mounted man lift is also equipped with safety devices such as manual emergency descent valves to ensure the safety of operators.     1.Flexible and efficient operation capability  The core feature of the Isuzu KV100 aerial platform truck is its folding boom structure, which consists of multiple sections and can be folded and extended flexibly like an arm. This design gives it a significant advantage in confined space or complex terrain.    For example, on construction sites, the folding boom truck crane can easily cross obstacles and accurately lift construction materials or equipment; in logistics warehouses, its flexible boom can efficiently complete cargo loading and unloading in a small space. In addition, the boom can rotate 360 ​​degrees, with a wide operating range, and can adapt to lifting needs at different heights and angles. Its hydraulic system drives the telescopic, rotating and lifting actions of the boom, which is easy and accurate to operate, further improving operating efficiency.     2.Features of Isuzu folding arm aerial work vehicle a.High flexibility: The arm of Isuzu...

In the field of urban sanitation and waste management, garbage compactor trucks are indispensable tools. The ISUZU NPR 4×4 garbage compactor truck, with its outstanding performance, reliable quality, and wide applicability, has become the preferred choice for many sanitation departments and waste management companies. This article will comprehensively analyze the unique value of the ISUZU NPR 4×4 garbage compactor truck from multiple perspectives, including the advantages and performance of the ISUZU 4×4 chassis, the working principles and technical features of the compactor truck, the reasons customers choose it, its application scenarios, and a comparison with 4×2 garbage compactor trucks.   1. Advantages and Performance of the ISUZU 4×4 Chassis1.1 All-Wheel Drive System: A Powerful Tool for Complex Road Conditions The ISUZU NPR 4×4 chassis is equipped with an advanced four-wheel drive system, featuring a transfer case and front/rear differential locks. This system provides excellent traction and off-road capability in slippery, muddy, or steep road conditions. This all-wheel-drive capability enables the garbage compactor truck to operate efficiently in various environments, such as narrow urban streets, unpaved rural roads, and mountainous slopes.     1.2 Powerful Engine and Efficient TransmissionThe NPR 4×4 chassis is powered by ISUZU's renowned 4HK1 series diesel engine, with a displacement of 5.2L, delivering a maximum power of 190 horsepower and a peak torque of 511 N·m. The engine incorporates high-pressure common rail fuel injection technology and a turbocharged intercooler system, ensuring not only strong power but also excellent fuel efficiency and low emissions. It is paired with a 6-speed manual or automatic transmission, offering high transmission efficiency and smooth operation.1.3 High Load Capacity and Robust Chassis StructureThe NPR 4×4 chassis is constructed with high-strength steel, providing exceptional load capacity and durability. With a gross vehicle weight (GVW) rating of up to 11 tons, it can easily meet the demands of an 8-cubic-meter garbage compactor truck. Key areas of the chassis are specially reinforced, ensuring stability and safety even under full load conditions.     2. Working Principles and Technical Features of the ISUZU 4×4 Garbage Compactor Truck2.1 Garbage Compression and LoadingThe ISUZU 4×4 refuse compactor truck is equipped with an efficient garbage compression device and hydraulic system. Waste is loaded into the garbage bin through the rear or side loading port, and the hydraulic system drives the compression plate to compact the waste to its maximum density, significantly increasing loading capacity. The compressed waste density can reach 600-700 kg/m³, reducing the number of trips required and improving operational efficiency.2.2 Hydraulic System and Control SystemThe hydraulic system of the compactor tr...

Isuzu fire fighting truck is an important tool for rescue and fire fighting. It has a special structure and functions to meet the needs of firefighters for rescue and fire fighting tasks. The fire truck can carry various types of fire fighting equipment, so its structure must be able to support the installation and operation of these equipment.  After the Isuzu fire truck is completed, the rain test is very important to evaluate its waterproof sealing performance in rainy or humid environments and ensure that key parts such as the cab, passenger room, equipment box, and pump room equipped with electrical equipment will not leak. The following will provide a detailed introduction to the fire truck from production to completion, and finally the rain test.   ►1.Determine the production drawings of Isuzu fire truck  The production drawings of Isuzu fire truck are the core technical documents for manufacturing fire trucks, which specify the structure, size, materials and assembly process of the vehicle in detail. The drawings usually include general assembly drawings, component drawings and parts drawings, covering key parts such as the body, chassis, water pump system, water tank, fire equipment compartment, etc. The design should fully consider functionality and safety, such as fireproof and leakproof performance, load capacity and ease of operation. ►2.Install the sandwich power take-off  The sandwich power take-off is the power output device of the Isuzu fire engine, which is responsible for transmitting the power of the engine to the fire pump. Installing the sandwich power take-off is the first and most critical step in the manufacture of the fire engine. During the installation process, it is necessary to ensure that the connection between the power take-off and the engine and gearbox is firm and reliable, and the gap and position of the power take-off are adjusted in strict accordance with the technical requirements to ensure smooth and noiseless operation. After the installation is completed, a trial run is also required to check whether the power take-off is working properly and whether there are any abnormal noises, oil leakage and other problems.     ►3.Install the box body  The box body is an important part of the Isuzu fire truck, which is used to store firefighting equipment and water sources. When installing the box body and tank body, it is necessary to ensure that they are firmly connected to the chassis and sealed to prevent water leakage. At the same time, various valves, interfaces and instruments need to be installed according to the design requirements to ensure that they are easy to operate and accurate in indication. During the installation process, special attention should be paid to the material and thickness of the box and tank to ensure that they can withstand high pressure and high temperature to meet the needs of firefighting operations. After the installation is completed, a pressure t...

Exploration of commonly used fire pumps and fire monitors: Taking Shanghai Xiongzhen fire pump and Chengdu West fire monitor as examples The fire truck is the most powerful weapon at the fire scene, and the fire pump and fire monitor are the core equipment on the fire truck. They are responsible for providing fire extinguishing water source and long-distance spraying of fire extinguishing agent respectively. Today, we will take Shanghai Xiongzhen fire pump and Chengdu West fire monitor as examples to explore these two types of fire fighting equipment.    Shanghai Xiongzhen Fire Pump The fire pumps produced by Shanghai Xiongzhen Fire Equipment Co., Ltd. are widely used in the field of firefighting and rescue.   CB10/20, CB10/30 and CB10/40 fire pumps CB10/20-XZ, CB10/30-XZ and CB10/40-XZ low-pressure vehicle fire pumps adopt a single-stage centrifugal water pump and a two-piston water diversion device. When the pump rotates, it drives the water diversion device, and the water diversion device automatically disengages after the pressure is met. The product has stable operation and reliable quality, and can be equipped with a variety of water inlet and outlet pipes. It is a high-efficiency, large-flow, stable low-pressure output special pump for fire trucks, which is widely used in various small and medium-sized fire trucks.   Features ● Large flow and stable pressure: CB10/20-XZ rated flow 20L/s, CB10/30-XZ rated flow 30L/s, CB10/30-XZ rated flow 40L/s, rated pressure 1.0MPa, which can meet the needs of general fire fighting.   ● Compact structure and light weight: It adopts lightweight design, compact structure, and is easy to install and maintain.   ● Smooth operation and low noise: High-quality hydraulic models and precision processing technology are used to ensure smooth operation and low noise.   ● High reliability and long service life: Key components are made of high-quality materials and have undergone rigorous testing to ensure that the product is reliable and durable.       CB10/60 Fire Pump The CB10/60-XZ low-pressure vehicle fire pump is independently developed and designed by Xiongzhen. It adopts a single-stage guide vane structure with balanced, stable and reliable water output. It adopts an electric two-piston water diversion device, which has a short water diversion time and is easy to operate. It is a low-pressure and high-flow vehicle fire pump suitable for various types of fire trucks, such as light, medium and heavy fire trucks. Especially in occasions where a large flow of water is required, such as urban high-rise building fires, large commercial complex fires, etc. It can quickly provide a stable high-pressure water flow and provide strong firefighting support for firefighters. Technical Features High efficiency and energy saving: adopts a single-stage guide vane structure, and the water output is balanced, stable and reliable. The electric two-piston water dive...

The entire Isuzu chassis production line uses high-precision welding robots, combined with a laser vision sensor system, to achieve real-time identification and adaptive adjustment of welds. Refined manufacturing, known for its sturdiness, durability, and large load, low noise, abundant power, and good fuel-saving performance, which is essential for fire trucks that need to be frequently dispatched and run for a long time.     At the same time, the Isuzu engine can maintain a very stable working state, which is essential for the reliability of fire trucks in emergency situations. And it has good adaptability and versatility, which can meet the modification needs of different types of fire trucks. The high degree of standardization of Isuzu chassis makes the modification process more convenient and efficient. It is easier to install the required firefighting equipment and devices on the Isuzu chassis, thereby shortening the modification cycle and reducing costs.     Let's learn about the four major chassis types suitable for fire fighting truck modification:   1.ISUZU NKR mini-duty chassis: Engine Power: 120HP  Wheelbase: 3360mm Max speed: 95 km/h 2.ISUZU NPR light-duty chassis Engine Power: 190HP  Wheelbase: 3815mm Max speed: 95 km/h   3.ISUZU F-Series middle-duty chassis Engine Power: 205HP  Wheelbase: 4500mm Max speed: 90 km/h   4.ISUZU GIGA heavy-duty chassis Engine Power: 380P  Wheelbase: 4600mm Max speed: 85 km/h        Fire pump installation location and system description:       Isuzu fire trucks modified by Powerstar trucks factory, the fire pump is usually installed at the rear of the tank. This design helps to keep the truck balanced, improve firefighting efficiency, and facilitate operation and maintenance. Placing the pump at the rear of the tank helps to keep the Isuzu fire truck balanced, especially when fully loaded, ensuring that the Isuzu fire fighting truck is more stable during driving and reducing safety hazards caused by the shift of the center of gravity. In addition, the location of the pump at the rear of the tank makes it easier to pump water or fire extinguishing agent out of the tank and deliver it to the fire extinguishing equipment, reducing the length and resistance of the pipeline and improving the efficiency of firefighting. In actual operation, this layout also makes it easy for firefighters to approach the pump for necessary adjustments and inspections, which is conducive to the maintenance and replacement of the pump.         Which fire pump should be used for different Isuzu chassis?     As the core power system of Isuzu fire water truck, the structure and performance of fire pump are directly related to the efficiency and safety of fire fighting and rescue. Fire pumps are mainly divided into low-pressure pumps, medium-pressure pumps and high-pressure pumps, and each pump has its specific...
