The 4HK1-TCG60 is a heavy-duty inline-four diesel powertrain from Isuzu classical 4H series, manufactured by ISUZU in China. As a China VI emission-compliant version, also can be customized as EURO 6 emission standard, it is primarily designed for medium-duty commercial vehicles and various specialized modified chassis, including ISUZU NPR NQR NRR 700P cargo truck chassis, ISUZU GIGA 4X cargo truck chassis. Renowned for its robustness, durability, low failure rate, and excellent fuel efficiency, it is widely used in municipal sanitation vehicles, garbage trucks, tanker trucks, refrigerated trucks, and engineering specialty vehicles.      We POWERSTAR focus primarily on multiple diesel engine of ISUZU 4HK1-TCG60, and have below advanced features: High-Pressure Common Rail Fuel System: 4HK1 diesel engine with high-pressure common rail injection pressure reaches up to 1800 bar, precisely controlling injection timing and quantity for complete combustion, reduced fuel consumption, and lower exhaust pollutants, meeting the stringent China 6 / EURO 6 emission standards.Turbocharger + Intercooler: Provides high torque at low speeds, offering ample power for starting, heavy-load climbing, and is suitable for frequent start-stop operations in urban environments.China 6 / EURO 6 Rear Exhaust System: Equipped with a complete exhaust after-treatment system including DOC+DPF+SCR+ASC; requires the addition of automotive urea solution, eliminating the need for EGR exhaust gas recirculation, reducing the risk of carbon buildup inside the engine and extending its service life. Also can be customized to remove DPF and ADBlue system, also reprogram the truck ECU, then guarantee truck working as EURO 3, EURO 4, suitable for lower fuel quality.High-Strength Engine Block Structure: Cast iron cylinder block and wet cylinder liner design provide excellent heat dissipation and strong stability under prolonged high loads; the Isuzu 4HK1 engine block has been validated in millions of vehicles worldwide, ensuring high parts commonality and low maintenance costs.   ISUZU 4HK1-TCG60 diesel engine   5.193L Inline‑4 Turbo‑charged Intercooled Diesel PowerMax Power:151kW (205HP) @2600rpmMax Torque:647N·m @1600‑2600rpmEmission Standard: China‑VICommon‑rail Fuel Injection SystemHeavy‑duty Durability, Superior Fuel EconomyIdeal Power for Cargo Truck, Refrigerated Van, Sewage Suction Truck, Fuel Tanker & Special‑purpose Vehicles     Item Specification Model 4HK1‑TCG60 Cylinder Arrangement Inline 4‑cylinder, water‑cooled, 4‑stroke Displacement 5.193 L Intake System Turbocharged & Intercooled Fuel Injection System Electronic Common‑rail Injection Rated Maximum Power 151 kW (205 HP) Rated Speed 2600 rpm Peak Torque 647 N·m Peak Torque Speed Range 1600‑2600 rpm Emission Standard China‑VI Fuel Type 0# Diesel Fuel Transmission Matching Manual / Automatic clutch flywheel output, compatible with ISUZU MLD‑6Q 6‑speed transmission etc. Net Weight Approx. 430 kg Bore × Stroke 115 mm × 125 mm   4HK1-TCG60 model 205HP engine suitable for ISUZU Truck ⇓       Detailed Specification for ISUZU 4HK1 205HP diesel engine ⇓

RIV fire truck with full name as Rapid Intervention Vehicle, which specialized designed and produced based on compact, wildland type ISUZU T30 offroad 4x4 pickup truck chassis. The Dubai clients purchased and customized ISUZU 4x4 AWD RIV fire fighting truck is a small, alige, compact and quick response fire enginesequipped with 600L water tanker and 200L foam tanker, with independent fire pump device JBQ 5.5/10 model, efficiently flow rate is 10L/s, matched with PS20 fire monitor and 50m manual type hose reel and gun for efficiently water and foam jetting. As the modern designed RIV, the ISUZU pickup 4x4 fire apparatus are ideal for responding to emergencies in challenging environments. The relatively compact size and alige design allows the Quick Respon Fire Trucks to navigate narrow streets, rural roads and industrial sites. ISUZU pick up with 4x4 all wheel drive function guanartee them suitable for rough terrain, quick response fire service can be realized in fields, forests or construction sites, etc.  Dubai customer purchased ISUZU 4x4 offroad fire trucks are used for the international airport. Below showing detailed operation manual for ISUZU 4x4 pickup RIV rescue fire truck, which introduced of all functions of the Isuzu fire engine also the steps by steps to operate the truck correctly to avoid any misoperation.   Working Capacity  Engine Model Tire  Wheelbase  Superstructure  600L water+200L foam 4KH1/ 143HP  265/60R18 AT tire  3435mm ★ Water and foam tank stainless steel ★ China famous JBQ 5.5/10 independent fire pump ★ China famous PS20 Fire monitor ★ Customized 50m hose reel with jetting gun ★ 2026 year brand new   We POWERSTAR focus primarily on versatile platforms on ISUZU DAGA and T30 model pickup, the fire appliances are designed to tackle a range of challenging environments, from rural landscapes to urban areas. ISUZU tactical response fire vehicle combine durability, speed and fire suppression capabilities, allowing firefighters to respond quickly and effectively in critical situations. below detailed operation manual guidance for ISUZU RIV Fire Trucks service for variaty of fire scenarios, including airport fire rescue, wildland fires, hazardous material incidents. ⇓ Detailed video for How to operate ISUZU Pickup RIV Fire Truck       ISUZU 4x4 offroad pickup RIV fire trucks are customized rapid intervention vehicles are specialized for wildland fire fighting and emergency rescue. As the world most reliable Isuzu fire truck manufacturer, we POWERSTAR can not only provide reliable quality Isuzu pickup fire apparatus, RIV fire trucks, but also produced detailed English version documents for operation guidance and maintenance service, including Fire Truck Operation Manual, Isuzu Truck User Manual, Isuzu Spare Parts Manual, etc. Feel free to call us at 24 hours a day, 7 days a week.

The Isuzu straight boom aerial work platform trucks adopt original Isuzu chassis paired with a multi-section synchronous telescopic straight boom. Equipped with a mature hydraulic control system and multiple safety protection devices, it features a 360° rotating turntable, dual upper and lower operating positions, high mobility, and a large working range, making it the preferred equipment for high-altitude operations in open outdoor areas.   The working height of the aerial work platform truck ranges from 12-16 m, 18-21 m, 23 m, 27-28 m, 30 m, 33 m, 36 m, 42 m, to 45 m, 56 m, and 70 m, offering a wide working range. It also includes insulated booms and insulated buckets, providing a wide range of options. It is widely used in street light maintenance, garden pruning, power line repair, telecommunications construction, building exterior cleaning, billboard installation, and other situations requiring the transport of personnel and tools to heights for work. Product Features: • Chassis Advantages: Utilizes an original Isuzu chassis and is equipped with an original Isuzu diesel engine, providing powerful performance.   • Boom System: Employs a multi-section hexagonal or octagonal synchronous telescopic boom, featuring a compact structure, high operating efficiency, and a large working range; externally mounted telescopic cylinders and chain or wire rope telescopic mechanisms facilitate easy observation of fault points and maintenance.   • Outrigger System: Features front V-type and rear H-type or front V-type and rear V-type outriggers, offering good stability and allowing for simultaneous or individual operation to adapt to various working conditions.   • Control System: Employs a CAN bus control system equipped with electro-hydraulic proportional valves, enabling simultaneous dual-action and stepless speed regulation; displays are provided for both upper and lower sections to show real-time operating conditions.   • Safety Features: Includes multiple safety protections such as automatic interlocking during upper and lower sections, level detection, emergency electric pump, emergency stop device, and automatic amplitude limiting alarm. This instruction manual provides a detailed overview of the vehicle's structure, operational scope diagrams, operating procedures, safety precautions, emergency response plans, and maintenance requirements. All operators must thoroughly read this manual before starting work and strictly adhere to the safety operating procedures. Standardized operation not only improves work efficiency but is also a core safeguard against accidents involving working at heights. Please keep this manual with you at all times.   Download available at the beginning of this article.

Offroad 4x4 Isuzu GIGA 4 wheeler foam tanker fire truck is a special customized on ISUZU GIGA 5X type II automobile chassis. designed as 4x4 offroad driving model for wildland fire fighting, 4000mm short wheelbase guarantee whole length within 7500mm. Also 14.00R20 all terrain tires specialized for offroad and forest driving. ISUZU 6HK1 300HP forest rescue fire apparatus is specially customized produced for fire fighting and rescue tasks in wildland of Albania, equipped the double-row cabinet, with a crew of 2 + 4 independent SCBA seats, suitable and convenient for fire apparatus usage. The fire tanker upper body kit are equipped with 3000Liters water and 500Liters foam tanks. The equipment box is made of high-quality aluminum alloy roller shutter door. Powerful Shanghai Xiongzhen CB10/40 atmospheric fire pump installed in the rear pump room of the fire apparatus, can stably output 40L/s flow at 1.0MPa; The roof is installed with the PL8/32 fire cannon produced by Chengdu West Fire Equipment Co., Ltd., with a flow rate of 32L/s, a corresponding pressure of 0.8MPa, a maximum pressure of 1.3MPa, and a range of 60m water and 50m foam, which can be rotated 360°. At the same time, the car has the characteristics of high specific power, strong comprehensive performance, and simple control. Below showing detailed operation manual for ISUZU 4x4 fire truck, which introduced of all functions of the Isuzu fire engine also the steps by steps to operate the truck correctly to avoid any misoperation.   Working Capacity  Engine Model Tire  Wheelbase  Superstructure  3000L water+500L foam 6HK1/ 300HP  14.00R20 AT tire  4000mm ★ Water and foam tank stainless steel ★ China famous CB10/40-XZ fire pump ★ China famous PL8/32 Fire monitor ★ 2026 year brand new   Related Fire Truck: https://www.isuzutruckscn.com/isuzu-4x4-wheel-drive-fire-truck-for-honduras_p1847.html ⇓ Detailed video showing ISUZU GIGA 5X FVR Fire Truck Chassis   Albania clients customized ISUZU GIGA 5X FVR 3500Liters 4x4 wildland firefighting truck features a significally designed modular fire tanker superstructure, heavy duty fire agent storage, power fire pump and fire monitor for fire extinguisher working, also matched with integrated control panel for safety operation. Moreover truck prepared with English version User's Manual for operation guidance. All guarantee ISUZU 4x4 fire trucks with efficiently fire extinguishing ability and widely operational coverage, meeting the emergency rescue necessary of various scenarios specially for wildland and forest.       ISUZU GIGA 4x4 offroad wildland fire trucks equipped with 14.00R20 all terrain tires are specialized for wildland fire fighting and emergency rescue. As the world most reliable Isuzu fire truck manufacturer, we POWERSTAR can not only provide reliable quality Isuzu fire apparatus, but also produced detailed English version documents for operation guidance and maintenance service, including Fire Truck Operation Manual, Isuzu Truck User Manual, Isuzu Spare Parts Manual, etc. Feel free to call us at 24 hours a day, 7 days a week.    ISUZU GIGA 4x4 offroad wildland fire rescue truck ISUZU GIGA 300HP emergency 4x4 fire apparatus     Multiple Function of ISUZU Wildland Fire Truck ⇓ ISUZU 4x4 AWD fire truck for Fire Monitor Jetting   Top mounted with PL8/32 fire monitor, flow rate is 32L/s, efficiently for water and foam jetting, working distance for water can be 60m and foam can be 55m. Also top fire monitor can be used for multiple model jetting: Fog Type Water / Foam Jetting Straight Type Water / Foam Jetting   ISUZU 4x4 fire engine for Hose Reel Jetting   Customized 50m manual model fire fighting hose reel with control gun, which installed at rear of the fire pump room top position, with independent control valve for safety useage. Fog Type Water / Foam Jetting Straight Type Water / Foam Jetting     ISUZU forest fire truck Independent Gun Jetting   Two sides of the fire pump room equipped with totally 4 sets independent outlet control valve, which can be controlled separately. DN80 outlet valve for Water / Foam Jetting DN50 outlet valve for Water / Foam Jetting

The dumper is based on the Isuzu ELF mini double cabin chassis, and its core design concept revolves around efficient and reliable operation, versatility for both passenger and cargo transport, and suitability for urban distribution and engineering scenarios. Combining the excellent performance of the Isuzu ELF mini chassis, from the engine and transmission to its reliable load-bearing capacity, Powerstar truck has created an Isuzu light dump truck that balances practicality and durability.     Ⅰ.ISUZU ELF Double Cabin Chassis The Isuzu mini ELF double cabin chassis meets the needs of both passenger and cargo transport. The cab can accommodate 4-6 people, satisfying the needs of engineering teams and municipal work crews while retaining the loading and unloading efficiency of the self-unloading cargo box, perfectly balancing the two core scenarios of personnel commuting and material transportation.   Truck Model ISUZU ELF Mini Chassis Cabin Double Cab (5 person) Engine Diesel engine, 4KB1-TCG60, 96KW / 131HP, emission 2499cc Transmission MSB 5 shift manual gearbox Wheelbase 3815 mm Tire 700R16 Color Painting and Logos customized     From the engine and transmission to the chassis and rear axle, all components are manufactured to Isuzu's technical standards, featuring a high redundancy design for core parts, adaptable to high-frequency, high-intensity dumping operations. The narrow body and short wheelbase design improve maneuverability in narrow streets and construction site access roads. The lightweight dump truck body is matched with the powertrain, balancing load-bearing capacity and fuel economy.   Ⅱ.ISUZU ELF Double Cabin Dumper Truck Design Feature     ♦ The Isuzu 4KB1 series engine delivers a max horsepower of 132Ps and a peak torque of 360N・m, powerful hill climbing. ♦ It is paired with an Isuzu MSB-5MT manual transmission with a transmission efficiency of up to 98%. ♦ Combined fuel consumption is approximately 8-9L/100km. ♦ It features a reinforced Isuzu rear axle and leaf spring suspension. ♦ Equipped with 7.00R15LT heavy-duty tires, its rated load capacity meets the needs of transporting 3-5 tons of materials. ♦ The high-strength rectangular cargo box with a hydraulic lifting system allows for a wide lifting angle and clean unloading. ♦ It can accommodate 4-6 people, suitable for team operations and delivery services.       Ⅲ.ISUZU ELF Double Cabin Dumper Truck Application: • Municipal Engineering: Double-row seating accommodates team commutes, while the self-unloading function efficiently transports construction waste and slag. • Rural and Urban Distribution: Flexible vehicle body allows for easy movement on village and town roads, and the self-unloading cargo box facilitates loading and unloading of bulk goods such as sand, gravel, and agricultural supplies. • Urban Distribution Operations: Light truck body allows entry into urban areas, and environmental emissions meet urban management requirements.

Isuzu Giga QL1180JQFRCY 4HK1-TCG62 Truck Mounted Crane (also often called ISUZU 4HK1-TCG62 225HP Boom Crane Truck or GIGA ISUZU 225HP 10t Straight Boom Truck-Mounted Crane) have a very simple structure, consisting of a Isuzu GIGA cab chassis truck with model QL1180JQFRCY, a trailer, and a boom mounted on the front or rear of a flatbed cargo box. However, the boom of a truck-mounted crane is more versatile, operating like an arm with movable wrists and hands, enabling it to perform various lifting and unloading operations more flexibly.   Isuzu Giga QL1180JQFRCY 4HK1-TCG62 225hp Telescopic Boom Truck front right view     Isuzu Giga QL1180JQFRCY 4HK1-TCG62 225hp loader crane truck side view   QL1180JQFRCY ISUZU cab chassis truck mounted mobile crane rear right view      QL1180JQFRCY ISUZU cab chassis truck mounted mobile crane rear right view      Factory Isuzu Giga QL1180JQFRCY 4HK1-TCG62 cab chassis truck CAD drawing 4HK-TCG62 Mobile crane truck GIGA 225HP loader crane ISUZU GIGA Loader crane     ISUZU QL1180JQFRCY 4HK1-TCG62 cab chassis truck name plate picture   ISUZU QL1180JQFRCY 4HK1-TCG62 cab chassis truck front view   Powerstar Trucks as the most professional manufacturer of Isuzu truck-mounted cranes, providing customized truck-mounted crane services for the entire range of Qingling Isuzu models. From the 100P and KV800 series for light trucks, to the FVR and 700P series for medium trucks, and even the GIGA VC66 series for heavy trucks, we can precisely match your needs.   Leveraging the superior performance of the Isuzu chassis, our Isuzu cargo truck-mounted cranes combine powerful performance with stable load-bearing capacity, covering a full range of lifting capacities from 2 tons to 50 tons, meeting the diverse needs of urban delivery, construction projects, and logistics transportation. We also support personalized customization, creating efficient and reliable exclusive lifting and transportation solutions for you.

Fire fighting trucks is designed and manufactured for fire extinguishing and people rescue, which produced based on Top ISUZU brand truck chassis, modify with customized fire tanker body kit and equipped mutilple fire agent, including water, foam or dry power, also equipped full sets fire equipment and rescue tools. To guarantee ISUZU fire engine meet customer requirement, firstly choose suitable ISUZU truck chassis, then can 100% customize the type to meed clients requirement.   Isuzu GIGA 5X double cabin truck chassis Isuzu GIGA 5X double cabin truck chassis, mounted with Japanese ISUZU diesel engine 6HK1-TCG60 model with 221KW, 300HP and emission 7790cc, can be customized to reprogram ECU, remove the DPF and ADBlue system to guarantee truck working as EURO 3, 4 model, very suitable for Africa, Asia and South American countries. Details as below showing:   Truck Model ISUZU GIGA 5X Cargo Truck Chassis Cabin Customized double cabin Seat 1. Normal seat 2. Customized SCBA type seat for air apparatus Engine Diesel engine, 6HK1-TCG60, 221KW / 300HP, emission 7790cc Transmission FAST 9 shift manual gearbox Wheelbase 4500mm Tire 295/80R22.5, 315/80R22.5 Color Painting and Logos customized   ISUZU 300HP double cabin truck chassis Side view of ISUZU GIGA cargo truck chassis   To 100% guarantee clients have the most satify fire fighting trucks, we POWERSTAR R&D Department can prepare the official technical drawing for clients checking and confirm, then start production process. And based on clients required fire agent volume, the fire truck tanker body mainly have below two type for optional: Internal Tanker Type and Exteral Tanker Type.    Isuzu Fire Engine with Internal Tanker Assembly Internal tanker type means Isuzu fire engine designed with the tanker assembly fully hiden inside the frame assembly, and outside decorated with Aluminum alloy rolling doors.     ♥ Decorated with Aluminum alloy doors, flat and beautiful ♥ Internal designed and mounted, efficiently avoid freezing ♥ Designed to have more space for fire fighting equipment and rescue tools, convenient for usage ♥ Lower central of gravity to guarantee the driving more safety    Isuzu Fire Fighting Truck with External Tanker Assembly External tanker type means fire agent water tanker or foam tanker is expose outside, usually the water and foam tanker are designed as square type or rectangle type, then decorate the tanker system same color as fire truck, available as red RAL3000 or R03 model, very convenient for decorate and maintenance.   ♥ Tanker body kit exposed, which easily for daily checking and convenient for maintenance ♥ Reduced the frame assembly, lower selfweight ♥ Central of gravity can be designed mainly at rear axle, increased loading weight, specialized for heavy loading type   Isuzu GIGA 4x2 Rescue Pumper Fire Fighting Truck overview Our professional engineers will design the technical drawing of fire fighting trucks, then send for clients checking and confirm, after all OK will start manufacture process. below is sample type that well finished ISUZU GIGA 6 wheeler foam tanker fire engine.

ISUZU GIGA 6WG1 520hp Firefighting truck USERS MANUAL, also named isuzu giga foam water fire vehicle operation manual,  based on type II ISUZU GIGA VC66 model 6*4 Left Hand Drive chassis, body capacity could up to 12,000Liters, including 6,000Liters water tanker and 6,000Liters foam tank, truck equipped with XIONGZHEN CB10/140 fire pump and 2 sets fire monitors, including 1 set PL8/48 model and 1 set PL8/64 model, very convenient for daily use. Mainly used for firefighting project in any areas of need.   The Commercial ISUZU GIGA 6x4 Foam Fire Tender designed to fully rely on the advantages of the original of ISUZU brand truck chassis, fully consider the product's convenience and reliability, also the newly designed chassis ISUZU GIGA VC66 technology features. The body material is international standard carbon steel with anti-corrosion painting and stainless steel, which can effective to avoid rusting and service for long life.           The ISUZU GIGA VC66 6x4 Fire Truck equipped with Sandwich PTO, fire pump, fire monitor, crew room, hose box, pump room, dry powder tanker and nitrogen system, matched with pipeline hose reel, English version control box, inlet and outlet pipeline, rear climbing ladder, top pillow lamp, and all necessary firefighting equipment. Customized Double-row cabin with 2+4 seats nice driving feeling. Therefore, the vehicle is an ideal Fire Truck mainly for firefighting project.           Basic parameter: Items 6000liters Water & 6000liters Foam6 ISUZU GIGA 6x4 Fire Truck S I Z E Outer Dimension（L×W×H）(mm) 10040*2600*3570 Wheelbase  (mm) 4800+1370 W E I G H T Front Axle Capacity（kg） 9000 Rear Axle Capacity（kg） 13000+13000 Tank Capacity Water tanker 6000 L Foam tanker 6000 L Cab capacity（includes driver） Double Row 2+4 Tire 385/65R22.5 20PR/315/80R22.5 20PR   10+1 E N G I N Model 6WG1-TCG62 Type Six cylinder inline, water-cool, turbocharged Inter-cooling, diesel Rating Power（kW/HP） 381/520 Note: 1. The vehicle height includes fire monitor. 2. We keep the right to revise the parameters on the list above.   ISUZU GIGA 6WG1 520hp Firefighting truck France lanuage control box   Firefighting basic parameter list (1)                                                Model Items XIONGZHEN CB10/140 fire pump Fire Pump Model CB10/140 Flow (Low Pressure) 140 L/s at 1.0 Mpa Max suction depth(m) 7 Fire Monitor Model PL8/64 / PL8/48 Location Top Angle of rotation    360° Angle of elevation   ≥80° Angle of depression    ≤-10° Throw Water: ≥75 m; Foam: ≥70 m Installation    Two Fire Monitor can be used separately                                       Chapter 7, Maintenance of ISUZU GIGA foam water fire trucks 1. Cabin Check periodically whether the alarm lamp, electrical equipment, switches and fuse are in good state or not. If necessary, please make the maintenance and replacement in time.   2. Tank While the tank being full of extinguisher permanently, the extinguisher is corrosive for the tank. The tank should be checked periodically. Once it has been rusty, it is necessary to take some effective measures, preventing the rusty expanding. The common method is to clean the rusty point, after drying completely, brush it with epoxy resin paint. Also check the valves and pipeline periodically.   3. Hose box Check periodically whether there is sleeper in the hose box, whether the  roller door  is flexible or damage,  whether the oil of the chute of the door is lacking, whether the equipment are clean, dry and in good condition, whether the rubber rings of all joints are normal, whether the equipment are fixed firmly.   4. Pump room Check periodically whether the equipment in pump room are in good condition. If there are standing water and oil stain, it must be cleaned. Check whether the standing water and oil stain are results from system leakage, if it is, make the maintenance in time.    5. PTO, Transmission shaft Check the oil level and quality, change or add if necessary. Check the sound running state of PTO to find out whether it is blocked or spontaneous out-of-gear, if it is, check and repair in time. Check the sound of pump drive shaft. Check if all fasteners are tight or not.   6. Fire pump a．While working, add lubricant to each running part every 3-6 hours. b．Add lubricant to the screw thread of inlet and outlet, cover the cap. 7. Monitor and its pipeline Check all fasteners, joints, turning parts after using. Add lubricant to turning part periodically     8. Mi...
