This Isuzu NPR 700P 4x4 Automatic RHD Lubrication Service Truck is a service vehicle meticulously tailored for our clients by our POWERSTAR technical team. It is specifically designed for Road rescue, equipment refueling, equipment welding, and small-scale hoisting services, offering comprehensive functionality and high practicality.
▶ Truck Model : Isuzu 700P 4x4 RHD Automatic
▶ Speficiation : 3420L Diesel+500L Oil+500L Antifreeze+500L Waste+80L Grease
▶ Application Area : Road rescue, equipment refueling, equipment welding, and small-scale lifting services.
| Truck Item | Speficiation | Project Location |
| Isuzu 4x4 Automatic RHD Lube Service Truck | 5000 liters, 190 Hp engine | Road rescue department |
The PT5110ZHY Isuzu lubrication service vehicle is modified from an Isuzu NPR 700P all-wheel drive, automatic, right-hand drive chassis. It features an Isuzu 4HK1 190HP engine, an Allison automatic transmission, and all-wheel drive, providing ample power and ease of use. The vehicle has a 5-cubic-meter fuel tank, which can be used to refuel vehicles and equipment using the corresponding fuel nozzles. The crane can lift 1.5 tons, and the welding machine can operate using power from the vehicle's generator. The vehicle is fully functional and can meet the needs of our clients.
The superstructure integrates a generator set and air compressor to control the operation of diesel fuel, engine oil, antifreeze, waste oil, grease, crane, and welding machine. The vehicle is equipped with corresponding refueling devices, electrical systems, electronic control systems, hydraulic systems, and pneumatic systems to jointly control the operation of this multi-functional service vehicle.
▶ Technical Parameters
|
Isuzu 700P 4X4 RHD Automatic 5000L fuel lubrication service truck |
||||
|
General |
Brand |
Isuzu |
||
|
GVW |
10550kg |
|||
|
Wheelbase |
3815mm |
|||
|
Dimensions |
7590x2280x2600 mm |
|||
|
Front/Rear Axle loading |
4000/7000 kg |
|||
|
Cab |
Isuzu 700P 4x4 RHD Automatic type |
|||
|
Tire |
Qty |
6 pcs with one spare tire |
||
|
Specifications |
8.25R20 |
|||
|
Transmission |
Automatic gearbox |
|||
|
|
Brand |
Isuzu |
||
|
Model |
4HK1-TCG61 |
|||
|
Displacement |
5193 ml |
|||
|
Horsepower(HP) |
190HP/140kw |
|||
|
Cylinder type |
Inline 4 cylinder |
|||
|
Emission standard |
Euro 3 (remove DPF and ADblue system) |
|||
|
Fuel tank |
Tank material |
Tank material:Q235 high tensile strength steel. |
||
|
Thickness |
Side 5 Bottom 6(mm) |
|||
|
Tank capacity |
Diesel |
3420L |
||
|
Oil |
500L |
|||
|
Antifreeze |
500L |
|||
|
Waste |
500L |
|||
|
Grease |
2x40L |
|||
|
Hose reels |
Diesel Hose Reel : with 15m 32mm Diameter Hose and refueling gun |
|||
|
Oil Hose Reel : with 15m 32mm Diameter Hose and refueling gun |
||||
|
Antifreeze Hose Reel : with 15m 25mm Diameter Hose and refueling gun |
||||
|
Waste Hose Reel : with 15m 25mm Diameter Hose |
||||
|
1 spare Hose Reel: with 15m 32mm Diameter Hose |
||||
|
2 spare Hose Reel: with 15m 25mm Diameter Hose |
||||
|
Manhole cover |
4 manhole cover, ∮500mm 1 set with breather valve |
|||
|
External injection port |
Equipped for diesel,oil ,antifreeze |
|||
|
Equipment |
Generator,Air compressor,Crane,Welder,Top side light,2 tool box,Front bumper,Tow hook |
|||
|
Painting |
White |
|||
