Isuzu garbage compactor truck

The ISUZU GIGA 20CBM garbage compactor truck is an outstanding product of the powerstar trucks factory. With its 20 cubic meter efficient compression chamber, 380 horsepower and Euro 6 environmental protection standard, it can not only quickly and safely remove urban garbage, but also significantly reduce the volume of garbage and reduce the risk of secondary pollution, creating a cleaner and healthier living environment for urban residents. It reflects the profound pursuit of environmental protection and public health in modern urban governance and is an important symbol of urban civilization and progress.

Today we will discuss the core advantages of the ISUZU GIGA garbage rear loader:

The five core performance advantages of the ISUZU GIGA 20CBM rear loader are as follows:

1. Ultimate power system: The 6UZ1-TCG61 engine is equipped with turbocharging and intercooling technology, with an output of 380 horsepower and a large displacement of 9.839L. It is not only powerful, but also fully meets the Euro 6 emission standards, reflecting the perfect balance between high efficiency, energy saving and environmental protection.

2. Leading load and stability: 6*4 drive configuration, 25 tons total weight, 12.7 tons actual load capacity, 7 tons front axle and 13 tons each on the double rear axle, ensuring excellent stability and strong passability under complex road conditions.

3. Intelligent garbage disposal: 1:3.4 high compression ratio, 20 cubic meters curved tank, single loading and unloading cycle time controlled at 40-45 seconds, PLC intelligent control system, to achieve high efficiency and accuracy of garbage disposal.

4. Excellent structure and craftsmanship: Made of Q235 special steel, the tank is 4mm thick, with 12 front and 1 rear gearbox and a maximum speed of 90km/h, showing the rigor and precision of the craftsmanship.

5. Comprehensive safety configuration: Equipped with multiple safety devices such as alarm, camera, emergency stop button, fire extinguisher, etc. English/localized control panel is provided, fully considering the operator's experience and safety needs.

The ISUZU GIGA 20CBM garbage compactor truck uses the ISUZU 6UZ1-TCG61 engine. The advantages of this compression garbage truck:

1. Engine performance advantage, 380 horsepower, providing strong power for large garbage trucks, 9.839L large displacement means better traction and climbing performance, the engine is 6-cylinder inline, water-cooled, turbocharged, intercooled, and has excellent comprehensive performance.

2. 2. Matching with the truck, the truck has a total weight of 25 tons, the engine power of 380 horsepower can fully meet the load requirements, 6*4 drive with a strong engine to ensure passability under complex road conditions. 12 forward gear gearbox, can finely adjust the power output.

3. Special advantages for garbage disposal, the engine's automatic control system is highly matched with the hydraulic system of the garbage rear loader truck, the low-speed torque is sufficient, suitable for garbage collection work with frequent start-stop. The cooling system is reliable to ensure stable performance during long-term work.

4. Economic performance, the fuel tank capacity is 400L, and the cruising range is long. The engine design focuses on fuel economy - the automatic control system helps optimize fuel consumption.

5. Reliability, six-stroke direct injection technology, less engine wear. Turbocharging and intercooling technology improve engine heat dissipation and performance stability.

The application of PLC system in compression garbage truck has significant advantages:

1. Precise control: The compression process is accurate to milliseconds, and the compression force, angle, and time can be precisely controlled, which increases the compression efficiency by 15-20%, reducing the risk of manual misoperation.

2. Intelligent management: Real-time data collection and monitoring, automatic recording of each garbage loading and unloading parameters, traceable operation trajectory and working status, and support for remote diagnosis and management.

3. System stability: Strong anti-interference ability, operating temperature range of -20℃ to 65℃, service life of up to 10-15 years, and failure rate lower than traditional hydraulic control systems.

4. Energy saving and environmental protection: Precisely control the energy consumption of the hydraulic system, reduce invalid energy consumption, real-time monitoring of oil temperature and pressure, and reduce energy consumption by about 20-25%.

5. Convenient maintenance: Modular design, fast fault location, remote firmware upgrade, and significantly reduced maintenance costs.
