ISUZU 10 cbm truck mounted garbage compactor
ISUZU 10 cbm truck mounted garbage compactor integrates a high-performance 4HK1-TCG60 diesel engine, This 5.2L inline-4 cylinder engine produces 190 hp at 2,600 rpm and generates 510 Nm torque at 1,600-2,000 rpm, compliant with China VI emission standards. Coupled with the MLD6S manual transmission system.
The compactor module employs a dual-cylinder hydraulic system operating at 18 MPa pressure, achieving a 4:1 compression ratio to maximize waste density within the 10.5m³ cargo compartment. Its 220L hydraulic oil tank supports continuous compaction cycles, while the PLC-controlled system enables semi-automatic loading/compaction cycles.
Work capacity:
10 CBMEngine power:
190 HPEngine type:
4HK1-TCG61Axle drive:
4x2, left hand driveGear box:
MLD 6-speed,manualRemarks:
Hardox material optionalISUZU 10 cbm garbage compactor integrates isuzu 700P medium chassis, siemens compaction mechanism, and waste containment system. ISUZU 10 cbm truck mounted garbage compactor foundation utilizes an ISUZU NPR series truck platform featuring a reinforced ladder-type frame with cross-members spaced at 300mm intervals to withstand dynamic compaction forces. Mounted on this chassis is a 4.5mm thick high-tensile steel compactor body divided into 7m³ loading chamber and 3.2m³ compression zone.
The compaction system employs a dual-stage hydraulic press with a 140mm bore cylinder generating 12-ton force. A unique scissor-type compaction panel design ensures 360° waste compression through its trapezoidal blade configuration. Hydraulic power derives from a PTO-driven gear pump delivering 45L/min at 16MPa, controlled by an electro-hydraulic proportional valve system.
The hopper incorporates a 8mm thick abrasion-resistant steel floor with 15° inclined geometry for optimal load distribution. A sliding ejector plate with polyurethane edge seals facilitates complete waste discharge, operated by twin 100mm bore cylinders with 1,200mm stroke length. The loading aperture features a reinforced 1,800×900mm tailgate with interlocking cam mechanism and safety limit switches.
● No 1 garbage compactor truck factory & Manufacturer
● 30 years professional experience
● OEM, ODM customization to your requirements
● 40HQ container shipping solution.
Product Specifications
|
Product Name |
ISUZU 8CBM Hydraulic Garbage Compactor |
|
Chassis Model |
lSUZU 700P (NPR) |
|
Driving Type |
4*2 |
|
Gross Vehicle Weight |
11000kg |
|
Related Loading Mass |
3750kg |
|
Curb Weight |
6800kg |
|
Air condition |
Cooling/heating |
|
Overall Dimensions |
7500×2300×2580(mm) |
|
Wheelbase |
3815 (mm) |
|
Front/rear Axle Loading Capacity |
4000/7000kg |
|
Approach angle |
17° |
|
Departure angle |
13° |
|
Front/rear Suspension |
1110/2095(mm) |
|
Tire |
235/75R17.5 16PR, 6+1 PCS |
|
Max Speed |
110(Km/h) |
|
Engine parameters |
|
|
Model |
4HK1-TCG61 |
|
Horse Power |
190hp |
|
Displacement |
5193cc |
|
Emission Standard |
Euro 6 |
|
Type |
4 stroke, 4 cylinders, in-line, water cooling |
|
Gear Box |
|
|
Model |
lSUZU MLD |
|
Gears |
6 forward and 1 reverse, manual |
|
Superstructure Parameters |
|
|
Compactor Body Volume |
8CBM |
|
Tank Shape |
Arc-shape/Square Optional |
|
Tank Material thickness |
Bottom: 4 mm; Side: 5 mm |
|
Tank Material |
T420 special steel |
|
Compression Ratio |
≥2.5 |
|
The effective volume of the tailgate |
≥0.8m³ |
|
Loading cycle time |
≤40 s |
|
unload garbage time |
≤45s |
|
control method |
Automatic, Manual |
|
Maximum pressure of hydraulic system |
18 MPa |
|
Control System |
CAN-bus |
|
Operate Mode |
Automatic & Manual |
|
Bin lifter |
Available for 120L, 240L, 660L and 1100L garbage bins |
The ISUZU 8 CBM Rear-Loading Trash Truck serves as a versatile waste management solution for urban and suburban environments. Below is a structured overview of its key applications:
High-Efficiency Waste Collection
Equipped with a rear-loading mechanism and hydraulic compaction system, this truck streamlines refuse collection. Its 8-cubic-meter capacity, combined with a 3:1 compression ratio, reduces transport frequency by consolidating large volumes of residential and commercial waste.
Municipal Infrastructure Compatibility
Specifically engineered for narrow streets and high-density areas, the compact chassis design facilitates maneuverability in constrained urban layouts. The rear-load configuration aligns with standardized container systems, enabling seamless integration with existing municipal waste collection protocols and public sanitation workflows
Multipurpose Waste Handling
Beyond routine household waste, this model processes green waste, construction debris, and recyclables through customizable configurations. Optional features include weight sensors for payload optimization and GPS-integrated fleet management systems, enhancing route efficiency for municipal authorities and private contractors alike.
The operational workflow of the ISUZU 10m³ truck-mounted garbage compactor begins with pre-inspection protocols. Operators verify hydraulic oil levels, check electrical systems, and ensure safety mechanisms like emergency stops are functional. The compactor's power take-off (PTO) system is engaged only after the truck engine reaches optimal operating temperature.
During loading procedures, workers deposit waste into the roof-mounted hopper while maintaining safe distance from moving components. The operator activates the automated loading cycle through the CANbus control panel, triggering the pre-compaction blade to distribute material evenly within the 10m³ chamber. Advanced load sensors monitor waste density, preventing over-compaction that could strain the 4-stage hydraulic system.
Compression cycles utilize a synchronized combination of the horizontal packer and vertical compactor plate, achieving up to 5:1 volume reduction. Operators monitor real-time pressure gauges to maintain optimal force between 12-15MPa, ensuring efficient compaction without exceeding the 10-tonne payload capacity. The integrated weight sensor alerts operators when approaching maximum capacity.
